openstack v版 centos stream 8 手工搭建——Neutron搭建(六)

本文最后更新于85 天前，其中的信息可能已经过时，如有错误请发送邮件到2639131093@qq.com

注意

1.本教程为openstack 搭建平台victoria 版，虚拟机为centos stream 8

2.本教程设计内容非常多，很复杂，但也很有技巧，请注意每一步，我说可以更改的地方可以更改，其余建议和我一样

3.内容板块大体包括：基础环境设置， keystone组建安装，glance组建安装，placement组建安装，nova组建安装，neutron组建安装，dashboard组建安装

4.密码约定：本文所有和数据库及消息队列相关的密码统一设定 rootroot，openstack 组件用户密码统一设定 redhat

5.学习此章节，你需要了解的知识：数据库sql中dcl用户管理的知识，linux基础命令，openstack基础命令

6.官方网址：

OpenStack Docs: Install and configure controller node

7.环境配置：

环境用到 2台虚拟机，单网卡，并为其配置静态 IP 及 DNS

主机名	ip	网关	DNS	cpu/内存	磁盘	角色	备注
controller	192.168.100.128	192.168.100.2	114.114.114.114	4c/6g	100g	控制节点	开启虚拟化引擎
compute	192.168.100.129	192.168.100.2	114.114.114.114	4c/6g	100g	计算节点	开启虚拟化引擎

控制节点

建库及授权

[root@controller ~(admin)]$ source keystonerc_admin
[root@controller ~(admin)]$ mysql -uroot -prootroot
Welcome to the MariaDB monitor.  Commands end with ; or \g.
Your MariaDB connection id is 104
Server version: 10.3.28-MariaDB MariaDB Server

Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

MariaDB [(none)]> create database neutron;
Query OK, 1 row affected (0.000 sec)

MariaDB [(none)]> grant all privileges on neutron.* to 'neutron'@'localhost' identified by 'rootroot'
    -> ;
Query OK, 0 rows affected (0.006 sec)

MariaDB [(none)]> grant all privileges on neutron.* to 'neutron'@'%' identified by 'rootroot';
Query OK, 0 rows affected (0.001 sec)

MariaDB [(none)]> show databases;
+--------------------+
| Database           |
+--------------------+
| glance             |
| information_schema |
| keystone           |
| mysql              |
| neutron            |
| nova               |
| nova_api           |
| nova_cell0         |
| performance_schema |
| placement          |
+--------------------+
10 rows in set (0.001 sec)

创建用户及关联角色

[root@controller ~(admin)]$ openstack user create --domain default --password-prompt neutron
User Password:  ## redhat
Repeat User Password:
+---------------------+----------------------------------+
| Field               | Value                            |
+---------------------+----------------------------------+
| domain_id           | default                          |
| enabled             | True                             |
| id                  | aa11f2ae54f3443193d454bf49c64037 |
| name                | neutron                          |
| options             | {}                               |
| password_expires_at | None                             |
+---------------------+----------------------------------+
[root@controller ~(admin)]$ openstack role add --project service --user neutron admin
[root@controller ~(admin)]$ openstack role assignment list --user neutron
+----------------------------------+----------------------------------+-------+----------------------------------+--------+--------+-----------+
| Role                             | User                             | Group | Project                          | Domain | System | Inherited |
+----------------------------------+----------------------------------+-------+----------------------------------+--------+--------+-----------+
| 35eb6220a4b14503b1672de9f0ffcae9 | aa11f2ae54f3443193d454bf49c64037 |       | 578eca45e7e549858c97314e3f2ec1e3 |        |        | False     |
+----------------------------------+----------------------------------+-------+----------------------------------+--------+--------+-----------+
[root@controller ~(admin)]$ openstack user list
+----------------------------------+-----------+
| ID                               | Name      |
+----------------------------------+-----------+
| cda7fc3c6ff74289b8f40e149d397710 | admin     |
| 9688822b0dcd41929430ab48335fceb2 | myuser    |
| 2c401bee20a245ac88cf4629ed4ee440 | glance    |
| 3e66c60b57354be89ac3d5e85fb2f485 | placement |
| 0c39c2efcb144276b82ac8fb249655b2 | nova      |
| aa11f2ae54f3443193d454bf49c64037 | neutron   |
+----------------------------------+-----------+

创建服务及注册API

应该是16个
[root@controller ~(admin)]$ openstack service create --name neutron --description "OpenStack Networking" network
+-------------+----------------------------------+
| Field       | Value                            |
+-------------+----------------------------------+
| description | OpenStack Networking             |
| enabled     | True                             |
| id          | 9688ea07b16a4f909352edc646485cb1 |
| name        | neutron                          |
| type        | network                          |
+-------------+----------------------------------+
[root@controller ~(admin)]$ openstack endpoint create --region RegionOne network public http://controller:9696
+--------------+----------------------------------+
| Field        | Value                            |
+--------------+----------------------------------+
| enabled      | True                             |
| id           | 75f6308dc2f64017a93678b3e1ab55a8 |
| interface    | public                           |
| region       | RegionOne                        |
| region_id    | RegionOne                        |
| service_id   | 9688ea07b16a4f909352edc646485cb1 |
| service_name | neutron                          |
| service_type | network                          |
| url          | http://controller:9696           |
+--------------+----------------------------------+
[root@controller ~(admin)]$ openstack endpoint create --region RegionOne network internal http://controller:9696
+--------------+----------------------------------+
| Field        | Value                            |
+--------------+----------------------------------+
| enabled      | True                             |
| id           | 29f8e63e955f4665be02d1d6cf2bf699 |
| interface    | internal                         |
| region       | RegionOne                        |
| region_id    | RegionOne                        |
| service_id   | 9688ea07b16a4f909352edc646485cb1 |
| service_name | neutron                          |
| service_type | network                          |
| url          | http://controller:9696           |
+--------------+----------------------------------+
[root@controller ~(admin)]$  openstack endpoint create --region RegionOne network admin http://controller:9696
+--------------+----------------------------------+
| Field        | Value                            |
+--------------+----------------------------------+
| enabled      | True                             |
| id           | 3192fcc291544c4780073fa0f9eaa1c4 |
| interface    | admin                            |
| region       | RegionOne                        |
| region_id    | RegionOne                        |
| service_id   | 9688ea07b16a4f909352edc646485cb1 |
| service_name | neutron                          |
| service_type | network                          |
| url          | http://controller:9696           |
+--------------+----------------------------------+
[root@controller ~(admin)]$ openstack endpoint list
+----------------------------------+-----------+--------------+--------------+---------+-----------+-----------------------------+
| ID                               | Region    | Service Name | Service Type | Enabled | Interface | URL                         |
+----------------------------------+-----------+--------------+--------------+---------+-----------+-----------------------------+
| 0347ebc573814319b61f2b061d12a76d | RegionOne | glance       | image        | True    | internal  | http://controller:9292      |
| 29f8e63e955f4665be02d1d6cf2bf699 | RegionOne | neutron      | network      | True    | internal  | http://controller:9696      |
| 3192fcc291544c4780073fa0f9eaa1c4 | RegionOne | neutron      | network      | True    | admin     | http://controller:9696      |
| 5b07ad93e892406da4bac5dd0338e3cf | RegionOne | placement    | placement    | True    | internal  | http://controller:8778      |
| 6395f0c625274f4b90e9137f38e93882 | RegionOne | keystone     | identity     | True    | admin     | http://controller:5000/v3/  |
| 75f6308dc2f64017a93678b3e1ab55a8 | RegionOne | neutron      | network      | True    | public    | http://controller:9696      |
| 810eab1198cc44dc8a2f4de04d227da4 | RegionOne | glance       | image        | True    | admin     | http://controller:9292      |
| 861dc3b20d324e4892e506058c2c7b1f | RegionOne | glance       | image        | True    | public    | http://controller:9292      |
| a0056090bca448f48158baec90bba5f3 | RegionOne | nova         | compute      | True    | admin     | http://controller:8774/v2.1 |
| a57a74e92f0143e4b13f6211f03a6c3d | RegionOne | nova         | compute      | True    | internal  | http://controller:8774/v2.1 |
| af379dafc84344b190a0b9bd0a08aa67 | RegionOne | nova         | compute      | True    | public    | http://controller:8774/v2.1 |
| ca45bbfeef81436688974a8d04e75d88 | RegionOne | keystone     | identity     | True    | internal  | http://controller:5000/v3/  |
| dc77bcd015344f4c9406495cba143841 | RegionOne | placement    | placement    | True    | admin     | http://controller:8778      |
| deb57dd079d1434b8ba2560d13aa8757 | RegionOne | placement    | placement    | True    | public    | http://controller:8778      |
| ff9d2f5be3c54026a27d8661b68460b9 | RegionOne | keystone     | identity     | True    | public    | http://controller:5000/v3/  |
+----------------------------------+-----------+--------------+--------------+---------+-----------+-----------------------------+

安装neutron包

太多啦
[root@controller ~(admin)]$ yum install openstack-neutron openstack-neutron-ml2 openstack-neutron-linuxbridge ebtables -y
已升级:
  iptables-1.8.5-11.el8.x86_64                   iptables-ebtables-1.8.5-11.el8.x86_64                   iptables-libs-1.8.5-11.el8.x86_64
已安装:
  conntrack-tools-1.4.4-11.el8.x86_64                    dibbler-client-1.0.1-10.el8.x86_64             dnsmasq-utils-2.79-33.el8.x86_64
  haproxy-1.8.27-5.el8.x86_64                            keepalived-2.1.5-9.el8.x86_64                  libnetfilter_cthelper-1.0.0-15.el8.x86_64
  libnetfilter_cttimeout-1.0.0-11.el8.x86_64             libnetfilter_queue-1.0.4-3.el8.x86_64          libunwind-1.4.0-5.el8s.x86_64
  lm_sensors-libs-3.4.0-23.20180522git70f7e08.el8.x86_64 net-snmp-agent-libs-1:5.8-26.el8.x86_64        openpgm-5.2.122-21.el8.x86_64
  openstack-neutron-1:17.4.1-1.el8.noarch                openstack-neutron-common-1:17.4.1-1.el8.noarch openstack-neutron-linuxbridge-1:17.4.1-1.el8.noarch
  openstack-neutron-ml2-1:17.4.1-1.el8.noarch            python3-beautifulsoup4-4.9.3-1.el8s.noarch     python3-designateclient-4.1.0-2.el8.noarch
  python3-gevent-1.2.2-4.el8.x86_64                      python3-logutils-0.3.5-11.el8s.noarch          python3-neutron-1:17.4.1-1.el8.noarch
  python3-neutron-lib-2.6.2-1.el8.noarch                 python3-os-ken-1.2.1-1.el8.noarch              python3-os-xenapi-0.3.4-1.el8.noarch
  python3-pecan-1.3.3-2.el8s.noarch                      python3-setproctitle-1.1.10-16.el8.x86_64      python3-soupsieve-2.1.0-1.el8s.noarch
  python3-tinyrpc-1.0.3-1.el8.noarch                     python3-waitress-1.4.4-1.el8s.noarch           python3-webtest-2.0.35-3.el8s.noarch
  python3-zmq-19.0.0-3.el8.x86_64                        radvd-2.17-15.el8.x86_64                       zeromq-4.3.2-1.el8.x86_64

编辑配置文件

编辑 neutron 配置文件

[database]                                                          ## 270
connection = mysql+pymysql://neutron:rootroot@controller/neutron

[DEFAULT]
core_plugin = ml2
service_plugins = router
allow_overlapping_ips = true
transport_url = rabbit://openstack:rootroot@controller         ##第一行
auth_strategy = keystone
notify_nova_on_port_status_changes = true
notify_nova_on_port_data_changes = true

[keystone_authtoken]
www_authenticate_uri = http://controller:5000
auth_url = http://controller:5000
memcached_servers = controller:11211
auth_type = password
project_domain_name = default
user_domain_name = default                                   ##370
project_name = service
username = neutron
password = redhat

[nova]
auth_url = http://controller:5000
auth_type = password                                          ##自己编写
project_domain_name = default
user_domain_name = default
region_name = RegionOne
project_name = service
username = nova
password = redhat

[oslo_concurrency]
lock_path = /var/lib/neutron/tmp                ##550

编辑 ml2 配置文件

[root@controller ~(admin)]$ vim /etc/neutron/plugins/ml2/ml2_conf.ini
##以下内容是都没有的，添加进去
[ml2]
type_drivers = flat,vlan,vxlan
tenant_network_types = vxlan
mechanism_drivers = linuxbridge,l2population
extension_drivers = port_security

[ml2_type_flat]
flat_networks = provider

[ml2_type_vxlan]
vni_ranges = 1:1000

[securitygroup]
enable_ipset = true

配置 Linux 网桥代理

[root@controller ~(admin)]$ vim /etc/neutron/plugins/ml2/linuxbridge_agent.ini
##依旧全部没有，添加到末尾
[linux_bridge]
physical_interface_mappings = provider:ens160

[vxlan]
enable_vxlan = true
local_ip = 192.168.100.128                 ##控制节点ip
l2_population = true

[securitygroup]
enable_security_group = true
firewall_driver = neutron.agent.linux.iptables_firewall.IptablesFirewallDriver

启用网桥支持

[root@controller ~(admin)]$ modprobe br_netfilter
[root@controller ~(admin)]$ sysctl net.bridge.bridge-nf-call-iptables
net.bridge.bridge-nf-call-iptables = 1
[root@controller ~(admin)]$ sysctl net.bridge.bridge-nf-call-ip6tables
net.bridge.bridge-nf-call-ip6tables = 1
[root@controller ~(admin)]$

配置三层代理

[root@controller ~(admin)]$ vim /etc/neutron/l3_agent.ini

##编辑以下内容

[DEFAULT]
interface_driver = linuxbridge

配置DHCP代理

[root@controller ~(admin)]$ vim /etc/neutron/dhcp_agent.ini
##这个就在最上面

[DEFAULT]
interface_driver = linuxbridge
dhcp_driver = neutron.agent.linux.dhcp.Dnsmasq
enable_isolated_metadata = true

配置元数据代理

[root@controller ~(admin)]$ vim /etc/neutron/metadata_agent.ini

##依旧最上面

[DEFAULT]
nova_metadata_host = controller
metadata_proxy_shared_secret = rootroot

配置计算服务

[root@controller ~(admin)]$ vim /etc/nova/nova.conf

[neutron]
auth_url = http://controller:5000
auth_type = password
project_domain_name = default
user_domain_name = default
region_name = RegionOne
project_name = service
username = neutron
password = redhat
service_metadata_proxy = true                            ##3510左右
metadata_proxy_shared_secret = rootroot

初始化数据库

[root@controller ~(admin)]$ ln -s /etc/neutron/plugins/ml2/ml2_conf.ini /etc/neutron/plugin.ini
[root@controller ~(admin)]$ su -s /bin/sh -c "neutron-db-manage --config-file /etc/neutron/neutron.conf --config-file /etc/neutron/plugins/ml2/ml2_conf.ini upgrade head" neutron
INFO  [alembic.runtime.migration] Context impl MySQLImpl.
INFO  [alembic.runtime.migration] Will assume non-transactional DDL.
  正在对 neutron 运行 upgrade...
INFO  [alembic.runtime.migration] Context impl MySQLImpl.
INFO  [alembic.runtime.migration] Will assume non-transactional DDL.
INFO  [alembic.runtime.migration] Running upgrade  -> kilo
INFO  [alembic.runtime.migration] Running upgrade kilo -> 354db87e3225
INFO  [alembic.runtime.migration] Running upgrade 354db87e3225 -> 599c6a226151
INFO  [alembic.runtime.migration] Running upgrade 599c6a226151 -> 52c5312f6baf
INFO  [alembic.runtime.migration] Running upgrade 52c5312f6baf -> 313373c0ffee
INFO  [alembic.runtime.migration] Running upgrade 313373c0ffee -> 8675309a5c4f
INFO  [alembic.runtime.migration] Running upgrade 8675309a5c4f -> 45f955889773
INFO  [alembic.runtime.migration] Running upgrade 45f955889773 -> 26c371498592
INFO  [alembic.runtime.migration] Running upgrade 26c371498592 -> 1c844d1677f7
INFO  [alembic.runtime.migration] Running upgrade 1c844d1677f7 -> 1b4c6e320f79
INFO  [alembic.runtime.migration] Running upgrade 1b4c6e320f79 -> 48153cb5f051
INFO  [alembic.runtime.migration] Running upgrade 48153cb5f051 -> 9859ac9c136
INFO  [alembic.runtime.migration] Running upgrade 9859ac9c136 -> 34af2b5c5a59
INFO  [alembic.runtime.migration] Running upgrade 34af2b5c5a59 -> 59cb5b6cf4d
INFO  [alembic.runtime.migration] Running upgrade 59cb5b6cf4d -> 13cfb89f881a
INFO  [alembic.runtime.migration] Running upgrade 13cfb89f881a -> 32e5974ada25
INFO  [alembic.runtime.migration] Running upgrade 32e5974ada25 -> ec7fcfbf72ee
INFO  [alembic.runtime.migration] Running upgrade ec7fcfbf72ee -> dce3ec7a25c9
INFO  [alembic.runtime.migration] Running upgrade dce3ec7a25c9 -> c3a73f615e4
INFO  [alembic.runtime.migration] Running upgrade c3a73f615e4 -> 659bf3d90664
INFO  [alembic.runtime.migration] Running upgrade 659bf3d90664 -> 1df244e556f5
INFO  [alembic.runtime.migration] Running upgrade 1df244e556f5 -> 19f26505c74f
INFO  [alembic.runtime.migration] Running upgrade 19f26505c74f -> 15be73214821
INFO  [alembic.runtime.migration] Running upgrade 15be73214821 -> b4caf27aae4
INFO  [alembic.runtime.migration] Running upgrade b4caf27aae4 -> 15e43b934f81
INFO  [alembic.runtime.migration] Running upgrade 15e43b934f81 -> 31ed664953e6
INFO  [alembic.runtime.migration] Running upgrade 31ed664953e6 -> 2f9e956e7532
INFO  [alembic.runtime.migration] Running upgrade 2f9e956e7532 -> 3894bccad37f
INFO  [alembic.runtime.migration] Running upgrade 3894bccad37f -> 0e66c5227a8a
INFO  [alembic.runtime.migration] Running upgrade 0e66c5227a8a -> 45f8dd33480b
INFO  [alembic.runtime.migration] Running upgrade 45f8dd33480b -> 5abc0278ca73
INFO  [alembic.runtime.migration] Running upgrade kilo -> 30018084ec99
INFO  [alembic.runtime.migration] Running upgrade 30018084ec99 -> 4ffceebfada
INFO  [alembic.runtime.migration] Running upgrade 4ffceebfada -> 5498d17be016
INFO  [alembic.runtime.migration] Running upgrade 5498d17be016 -> 2a16083502f3
INFO  [alembic.runtime.migration] Running upgrade 2a16083502f3 -> 2e5352a0ad4d
INFO  [alembic.runtime.migration] Running upgrade 2e5352a0ad4d -> 11926bcfe72d
INFO  [alembic.runtime.migration] Running upgrade 11926bcfe72d -> 4af11ca47297
INFO  [alembic.runtime.migration] Running upgrade 4af11ca47297 -> 1b294093239c
INFO  [alembic.runtime.migration] Running upgrade 1b294093239c -> 8a6d8bdae39
INFO  [alembic.runtime.migration] Running upgrade 8a6d8bdae39 -> 2b4c2465d44b
INFO  [alembic.runtime.migration] Running upgrade 2b4c2465d44b -> e3278ee65050
INFO  [alembic.runtime.migration] Running upgrade e3278ee65050 -> c6c112992c9
INFO  [alembic.runtime.migration] Running upgrade c6c112992c9 -> 5ffceebfada
INFO  [alembic.runtime.migration] Running upgrade 5ffceebfada -> 4ffceebfcdc
INFO  [alembic.runtime.migration] Running upgrade 4ffceebfcdc -> 7bbb25278f53
INFO  [alembic.runtime.migration] Running upgrade 7bbb25278f53 -> 89ab9a816d70
INFO  [alembic.runtime.migration] Running upgrade 89ab9a816d70 -> c879c5e1ee90
INFO  [alembic.runtime.migration] Running upgrade c879c5e1ee90 -> 8fd3918ef6f4
INFO  [alembic.runtime.migration] Running upgrade 8fd3918ef6f4 -> 4bcd4df1f426
INFO  [alembic.runtime.migration] Running upgrade 4bcd4df1f426 -> b67e765a3524
INFO  [alembic.runtime.migration] Running upgrade 5abc0278ca73 -> d3435b514502
INFO  [alembic.runtime.migration] Running upgrade d3435b514502 -> 30107ab6a3ee
INFO  [alembic.runtime.migration] Running upgrade 30107ab6a3ee -> c415aab1c048
INFO  [alembic.runtime.migration] Running upgrade c415aab1c048 -> a963b38d82f4
INFO  [alembic.runtime.migration] Running upgrade b67e765a3524 -> a84ccf28f06a
INFO  [alembic.runtime.migration] Running upgrade a84ccf28f06a -> 7d9d8eeec6ad
INFO  [alembic.runtime.migration] Running upgrade a963b38d82f4 -> 3d0e74aa7d37
INFO  [alembic.runtime.migration] Running upgrade 3d0e74aa7d37 -> 030a959ceafa
INFO  [alembic.runtime.migration] Running upgrade 030a959ceafa -> a5648cfeeadf
INFO  [alembic.runtime.migration] Running upgrade a5648cfeeadf -> 0f5bef0f87d4
INFO  [alembic.runtime.migration] Running upgrade 0f5bef0f87d4 -> 67daae611b6e
INFO  [alembic.runtime.migration] Running upgrade 67daae611b6e -> 6b461a21bcfc
INFO  [alembic.runtime.migration] Running upgrade 6b461a21bcfc -> 5cd92597d11d
INFO  [alembic.runtime.migration] Running upgrade 5cd92597d11d -> 929c968efe70
INFO  [alembic.runtime.migration] Running upgrade 929c968efe70 -> a9c43481023c
INFO  [alembic.runtime.migration] Running upgrade a9c43481023c -> 804a3c76314c
INFO  [alembic.runtime.migration] Running upgrade 804a3c76314c -> 2b42d90729da
INFO  [alembic.runtime.migration] Running upgrade 2b42d90729da -> 62c781cb6192
INFO  [alembic.runtime.migration] Running upgrade 62c781cb6192 -> c8c222d42aa9
INFO  [alembic.runtime.migration] Running upgrade c8c222d42aa9 -> 349b6fd605a6
INFO  [alembic.runtime.migration] Running upgrade 349b6fd605a6 -> 7d32f979895f
INFO  [alembic.runtime.migration] Running upgrade 7d32f979895f -> 594422d373ee
INFO  [alembic.runtime.migration] Running upgrade 594422d373ee -> 61663558142c
INFO  [alembic.runtime.migration] Running upgrade 61663558142c -> 867d39095bf4, port forwarding
INFO  [alembic.runtime.migration] Running upgrade 867d39095bf4 -> d72db3e25539, modify uniq port forwarding
INFO  [alembic.runtime.migration] Running upgrade d72db3e25539 -> cada2437bf41
INFO  [alembic.runtime.migration] Running upgrade cada2437bf41 -> 195176fb410d, router gateway IP QoS
INFO  [alembic.runtime.migration] Running upgrade 195176fb410d -> fb0167bd9639
INFO  [alembic.runtime.migration] Running upgrade fb0167bd9639 -> 0ff9e3881597
INFO  [alembic.runtime.migration] Running upgrade 0ff9e3881597 -> 9bfad3f1e780
INFO  [alembic.runtime.migration] Running upgrade 9bfad3f1e780 -> 63fd95af7dcd
INFO  [alembic.runtime.migration] Running upgrade 63fd95af7dcd -> c613d0b82681
INFO  [alembic.runtime.migration] Running upgrade c613d0b82681 -> c3e9d13c4367
INFO  [alembic.runtime.migration] Running upgrade c3e9d13c4367 -> 86274d77933e
INFO  [alembic.runtime.migration] Running upgrade 86274d77933e -> f4b9654dd40c
INFO  [alembic.runtime.migration] Running upgrade f4b9654dd40c -> a010322604bc
INFO  [alembic.runtime.migration] Running upgrade a010322604bc -> 263d454a9655
INFO  [alembic.runtime.migration] Running upgrade 263d454a9655 -> Ibac91d24da2
INFO  [alembic.runtime.migration] Running upgrade Ibac91d24da2 -> 2217c4222de6
INFO  [alembic.runtime.migration] Running upgrade 2217c4222de6 -> 18a7e90ae768
INFO  [alembic.runtime.migration] Running upgrade 18a7e90ae768 -> e4e236b0e1ff
INFO  [alembic.runtime.migration] Running upgrade e4e236b0e1ff -> e88badaa9591
INFO  [alembic.runtime.migration] Running upgrade e88badaa9591 -> d8bdf05313f4
INFO  [alembic.runtime.migration] Running upgrade d8bdf05313f4 -> dfe425060830
INFO  [alembic.runtime.migration] Running upgrade dfe425060830 -> fd6107509ccd
INFO  [alembic.runtime.migration] Running upgrade fd6107509ccd -> 1ea5dab0897a
INFO  [alembic.runtime.migration] Running upgrade 1ea5dab0897a -> 49d8622c5221
INFO  [alembic.runtime.migration] Running upgrade 49d8622c5221 -> I38991de2b4
INFO  [alembic.runtime.migration] Running upgrade 7d9d8eeec6ad -> a8b517cff8ab
INFO  [alembic.runtime.migration] Running upgrade a8b517cff8ab -> 3b935b28e7a0
INFO  [alembic.runtime.migration] Running upgrade 3b935b28e7a0 -> b12a3ef66e62
INFO  [alembic.runtime.migration] Running upgrade b12a3ef66e62 -> 97c25b0d2353
INFO  [alembic.runtime.migration] Running upgrade 97c25b0d2353 -> 2e0d7a8a1586
INFO  [alembic.runtime.migration] Running upgrade 2e0d7a8a1586 -> 5c85685d616d
  确定

启动服务

[root@controller ~(admin)]$ systemctl restart openstack-nova-api.service
[root@controller ~(admin)]$ systemctl start neutron-server.service neutron-linuxbridge-agent.service neutron-dhcp-agent.service neutron-metadata-agent.service
[root@controller ~(admin)]$ systemctl enable neutron-server.service neutron-linuxbridge-agent.service neutron-dhcp-agent.service neutron-metadata-agent.service
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-server.service → /usr/lib/systemd/system/neutron-server.service.
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-linuxbridge-agent.service → /usr/lib/systemd/system/neutron-linuxbridge-agent.service.
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-dhcp-agent.service → /usr/lib/systemd/system/neutron-dhcp-agent.service.
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-metadata-agent.service → /usr/lib/systemd/system/neutron-metadata-agent.service.
[root@controller ~(admin)]$ systemctl start neutron-l3-agent.service
[root@controller ~(admin)]$ systemctl enable neutron-l3-agent.service
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-l3-agent.service → /usr/lib/systemd/system/neutron-l3-agent.service.

计算节点

安装neutron包

[root@compute ~]# yum install openstack-neutron-linuxbridge ebtables ipset -y
已升级:
  iptables-1.8.5-11.el8.x86_64         iptables-ebtables-1.8.5-11.el8.x86_64
  iptables-libs-1.8.5-11.el8.x86_64    iptables-services-1.8.5-11.el8.x86_64
已安装:
  libunwind-1.4.0-5.el8s.x86_64
  openpgm-5.2.122-21.el8.x86_64
  openstack-neutron-common-1:17.4.1-1.el8.noarch
  openstack-neutron-linuxbridge-1:17.4.1-1.el8.noarch
  python3-beautifulsoup4-4.9.3-1.el8s.noarch
  python3-designateclient-4.1.0-2.el8.noarch
  python3-gevent-1.2.2-4.el8.x86_64
  python3-httplib2-0.10.3-4.el8.noarch
  python3-logutils-0.3.5-11.el8s.noarch
  python3-neutron-1:17.4.1-1.el8.noarch
  python3-neutron-lib-2.6.2-1.el8.noarch
  python3-os-ken-1.2.1-1.el8.noarch
  python3-os-xenapi-0.3.4-1.el8.noarch
  python3-osprofiler-3.4.0-2.el8.noarch
  python3-pecan-1.3.3-2.el8s.noarch
  python3-setproctitle-1.1.10-16.el8.x86_64
  python3-soupsieve-2.1.0-1.el8s.noarch
  python3-tinyrpc-1.0.3-1.el8.noarch
  python3-waitress-1.4.4-1.el8s.noarch
  python3-webtest-2.0.35-3.el8s.noarch
  python3-werkzeug-1.0.1-3.el8.noarch
  python3-zmq-19.0.0-3.el8.x86_64
  zeromq-4.3.2-1.el8.x86_64

编辑 neutron 配置文件

[DEFAULT]
transport_url = rabbit://openstack:rootroot@controller
auth_strategy = keystone                                  ##第一行

[keystone_authtoken]
www_authenticate_uri = http://controller:5000
auth_url = http://controller:5000
memcached_servers = controller:11211
auth_type = password
project_domain_name = default
user_domain_name = default                             ##370左右
project_name = service
username = neutron
password = redhat

[oslo_concurrency]
lock_path = /var/lib/neutron/tmp                       ##540左右

配置 Linux 网桥代理

[root@compute ~]# vim /etc/neutron/plugins/ml2/linuxbridge_agent.ini
##直接末尾添加全部
[linux_bridge]
physical_interface_mappings = provider:ens160

[vxlan]
enable_vxlan = true
local_ip = 192.168.100.129           ##compute节点ip
l2_population = true

[securitygroup]
enable_security_group = true
firewall_driver = neutron.agent.linux.iptables_firewall.IptablesFirewallDriver

启用网桥支持

[root@compute ~]# modprobe br_netfilter
[root@compute ~]# sysctl net.bridge.bridge-nf-call-iptables
net.bridge.bridge-nf-call-iptables = 1
[root@compute ~]# sysctl net.bridge.bridge-nf-call-ip6tables
net.bridge.bridge-nf-call-ip6tables = 1

配置计算服务

[root@compute ~]# vim /etc/nova/nova.conf

*** 找到对应标签并编辑以下内容 ***

[neutron]
auth_url = http://controller:5000
auth_type = password
project_domain_name = default
user_domain_name = default                     ##3510行
region_name = RegionOne
project_name = service
username = neutron
password = redhat

启动服务

[root@compute ~]# systemctl restart openstack-nova-compute.service
[root@compute ~]# systemctl start neutron-linuxbridge-agent.service
[root@compute ~]# systemctl enable neutron-linuxbridge-agent.service
Created symlink /etc/systemd/system/multi-user.target.wants/neutron-linuxbridge-agent.service → /usr/lib/systemd/system/neutron-linuxbridge-agent.service.

回到计算节点查看状态

[root@controller ~(admin)]$ openstack network agent list
+--------------------------------------+--------------------+------------+-------------------+-------+-------+---------------------------+
| ID                                   | Agent Type         | Host       | Availability Zone | Alive | State | Binary                    |
+--------------------------------------+--------------------+------------+-------------------+-------+-------+---------------------------+
| 50142428-588b-415f-b416-79015532f5f3 | Linux bridge agent | controller | None              | :-)   | UP    | neutron-linuxbridge-agent |
| ab696ed4-e450-4d81-9c51-e153342ff423 | Metadata agent     | controller | None              | :-)   | UP    | neutron-metadata-agent    |
| b6ed2be0-564c-4e14-b159-c3daaa9147e4 | DHCP agent         | controller | nova              | :-)   | UP    | neutron-dhcp-agent        |
| d5ce26f6-c0e1-4503-95cc-132ef731d2d0 | Linux bridge agent | compute    | None              | :-)   | UP    | neutron-linuxbridge-agent |
+--------------------------------------+--------------------+------------+-------------------+-------+-------+---------------------------+

cuo

社畜大二学生

注意

控制节点

建库及授权

创建用户及关联角色

创建服务及注册API

安装neutron包

编辑配置文件

编辑 neutron 配置文件

编辑 ml2 配置文件

配置 Linux 网桥代理

启用网桥支持

配置三层代理

配置DHCP代理

配置元数据代理

配置计算服务

初始化数据库

启动服务

计算节点

安装neutron包

编辑 neutron 配置文件

配置 Linux 网桥代理

启用网桥支持

配置计算服务

启动服务

回到计算节点查看状态

发送评论编辑评论

2024 年 11 月
一	二	三	四	五	六	日
				1	2	3
4	5	6	7	8	9	10
11	12	13	14	15	16	17
18	19	20	21	22	23	24
25	26	27	28	29	30

注意

控制节点

建库及授权

创建用户及关联角色

创建服务及注册API

安装neutron包

编辑配置文件

编辑 neutron 配置文件

编辑 ml2 配置文件

配置 Linux 网桥代理

启用网桥支持

配置三层代理

配置DHCP代理

配置元数据代理

配置计算服务

初始化数据库

启动服务

计算节点

安装neutron包

编辑 neutron 配置文件

配置 Linux 网桥代理

启用网桥支持

配置计算服务

启动服务

回到计算节点查看状态

发送评论 编辑评论

推荐文章

发送评论编辑评论
